SMLIGHT SLZB-MR3 - Multi Radio Adapter
AED 399.00
Out of stock
Radio Chips:
Texas Instruments CC2674P10
Zigbee 3.0 support (Zigbee2MQTT & ZHA compatible).
Thread (Matter-over-Thread) support (Open Thread Border Router) .
Ideal for Zigbee networks, works perfect also with Thread networks.
+20 dBm TX power with built-in PA.
Silicon Labs EFR32MG24
Zigbee 3.0 support (Zigbee2MQTT & ZHA compatible).
Thread (Matter-over-Thread) support (Open Thread Border Router).
Ideal for Thread networks, works perfect also with Zigbee networks.
+20 dBm TX power.
Supported Protocols:
Zigbee 3.0 (Zigbee2MQTT, ZHA), at the same time with Thread.
Thread (Matter-over-Thread), at the same time with Zigbee.
Supports simultaneous or switchable operation for multiradio environments.
Wi-Fi.
Connectivity:
USB-C for data and power
Ethernet connection
Firmware:
Radio firmware support
Compatible with TI Z-Stack (for CC2674P10)
Compatible with SL Ember/EZSP stack (for EFR32MG24).
Radio firmware Updating via web-interface
SLZB-OS
Compatible with SLZB-OS versions 2.8.7 and up.
SLZB-OS supported functionality:
VPN, 20+ languages, Scripts support, Network settings, Security, Dashboard, zHub mode, mode switcher, OTA firmware updates etc.
Antenna:
Dual external antenna SMA female connectors (one for each radio SoC)
PCB antenna for Wi-Fi and Bluetooth.
2x pre-packed high-gain 2.4 GHz antennas included
Power Supply:
PoE powered, POE 48V supported
Powered via USB-C (5V DC)
Low power consumption up to 1.5W (if both radio SoCs are running)
Enclosure:
Compact, durable ABS case with ventilation
DIN rail and wall-mount compatible (3D models)
Easy sticking with two-sided adhesive tapes
Easy mounting with screws with screw set (screws, screw driver, ruler) included.
LED Indicators and peripheral:
Independent status LEDs for each radio (6 service LEDs in total: 2 LEDs for Core SoC, 2 LEDs for CC2674P10 SoC, 2 LEDs for EFR32MG24 SoC,)
Multibutton: supports many functions (mode switch, reset etc).
