SMLIGHT SLZB-MR1 Multi Radio

Introducing the SLZB-MR1 Multi Radio — the ultimate solution for seamless connectivity! This state-of-the-art device boasts support for Zigbee, Bluetooth, Ethernet, Wi-Fi, and USB, ensuring comprehensive and versatile wireless connections. With features like over-the-air (OTA) updates, power over Ethernet, and multilingual support, the SLZB-MR1 is engineered for sophisticated integration needs. Ideal for VPN setup, IP66-rated environments, home automation integration (HA), Zigbee Hub Mode, and more, this multi-functional radio is a powerhouse of connectivity. Available in sleek, compact designs that easily blend into any setting, the SLZB-MR1 is your go-to choice for advanced network solutions.

Technical Specifications – SLZB-MR1

Radio Chips:

• Texas Instruments CC2652P7

• Zigbee 3.0 support (Zigbee2MQTT & ZHA compatible).

  • Thread (Matter-over-Thread) support (Open Thread Border Router) .

  • Ideal for Zigbee networks, works perfect also with Thread networks.

  • +20 dBm TX power with built-in PA.

  • 144kB+8kB RAM, 704kB Flash.

• Silicon Labs EFR32MG21

• Zigbee 3.0 support (Zigbee2MQTT & ZHA compatible).

  • Thread (Matter-over-Thread) support (Open Thread Border Router).

  • Ideal for Thread networks, works perfect also with Zigbee networks.

  • +20 dBm TX power.

  • 96 KB RAM, 1024 KB Flash.

Supported Protocols:

• Zigbee 3.0 (Zigbee2MQTT, ZHA), at the same time with Thread.

  • Thread (Matter-over-Thread), at the same time with Zigbee.

  • Supports simultaneous or switchable operation for multiradio environments.

  • Wi-Fi.

Connectivity:

• USB-C for data and power

• Ethernet connection

Firmware:

• Radio firmware support

  • Compatible with TI Z-Stack (for CC2652P7)

    • Compatible with SL Ember/EZSP stack (for EFR32MG21).

• Radio firmware Updating via web-interface

• SLZB-OS

• Compatible with SLZB-OS versions 2.6.8dev26, 2.8.3 and up (no inbetween 2.6.8 and 2.8.3).

• SLZB-OS supported functionality:

  • VPN, 20+ languages, Scripts support, Network settings, Security, Dashboard, zHub mode, mode switcher, OTA firmware updates etc.

Antenna:

• Dual external antenna SMA female connectors (one for each radio SoC)

• PCB antenna for Wi-Fi and Bluetooth.

• 2x pre-packed high-gain 2.4 GHz antennas included

Power Supply:

• PoE powered, POE 48V supported

• Powered via USB-C (5V DC)

• Low power consumption up to 1.5W (if both radio SoCs are running)

Enclosure:

• Compact, durable ABS case with ventilation

• DIN rail and wall-mount compatible (3D models)

• Easy sticking with two-sided adhesive tapes

• Easy mounting with screws with screw set (screws, screw driver, ruler) included.

LED Indicators and peripheral:

• Independent status LEDs for each radio (6 service LEDs in total: 2 LEDs for Core SoC, 2 LEDs for CC2652P SoC, 2 LEDs for EFR32 SoC,)

• Multibutton: supports many functions (mode switch, reset etc).
